Technical Specification
• Legalises trestles/bandstands and retains their well known flexible and easy to use reputation
• Provides 1100mm high fall protection for people, tools and materials
• Adjustable in height – Size 3 from circa 1050mm to 1560mm and Size 2 from circa 705mm to 1275mm
• Successfully load tested to BS 1139: Part 4
• Fully compliant to the Work at Height Regulations (WAHR 2005) both during erection, dismantling and use
• Handrail system successfully over-turning “topple” tested to BS EN 12811
• Ladder Restraint with integral safety gate
• Spacer bar “controls” the trestle centres, ensures scaffold boards are not over loaded which provides greater load bearing capacity and lateral stability
• Provides Class A Edge Protection to BS EN 13374
• The stabiliser is self levelling and provides full support even on un-flat ground conditions
• No tools required
• Co-invented by the user
Small Component Range:
Staybill – is a trestle/bandstand which includes the base stabiliser and spacer bar
Post – which fits into the base stabiliser and has the option of a C-Hook if required
Fixed or Hinged Guard – an integral handrail, toeboard and 50x50mm steel mesh panel
Ladder Restraint – with built –in safety gate and ladder stability device
H-Frame – to create “smooth” and supported scaffold board platforms to prevent slips, trips and flips
Staybills® guardrail system provides total flexibility and ease of use for all Construction Industry trades including Bricklayers and Masons, Plasterers, Joiners, Steel, Pre-cast or Timber frame erectors, Cladders and Window Installers, Plasterers, Mechanical and Electrical installers, Painters and Decorators and for Building Maintenance Works.
Staybills® has also been used in Pre-cast concrete manufacturing yards, for portable accommodation construction, petro-chemical applications – and can be used for many more applications.
